HUAWEI AX2 – WiFi 6

Wi-Fi Router Specifications

Dimensions & Weight

• Height: 29 mm
• Width: 257.6 mm
• Depth: 163.5 mm
• Weight: Approx. 216 g (without packaging)

Wi-Fi

• Transmission Standard:
  • 802.11ax/ac/a/n 2×2 & 802.11b/g/n 2×2, MIMO
• Wireless Transmission Rate:
  • 2.4 GHz: Up to 300 Mbps
  • 5 GHz: Up to 1201 Mbps
• Wireless Frequency Band: 2.4 GHz & 5 GHz

Memory

• RAM: 128 MB
• ROM: 128 MB

Network Ports

• Ports: Three 10/100/1000 Mbps WAN/LAN ports (Auto-adaptive)

Interface

• Ports: Power port, Network port, WPS/Reset button
• LED Indicator: 1 LED Indicator

Power Supply

• Power Consumption: < 12W
• Input: 12V DC, 1A

Software Functions

• App Support: HUAWEI AI Life App
• Features:
  • 802.11kv protocol
  • IPv4/IPv6
  • Wi-Fi Timer
  • Guest Wi-Fi
  • Device Speed Limiting
  • MAC Address Filtering
  • Parental Control
  • VPN Pass-Through
  • DMZ/Virtual Server
  • WAN Connection: PPPoE, DHCP, Static IP, Bridge

Security

• Encryption: WPA3
• Security Features:
  • Wi-Fi Access Control
  • Guest Wi-Fi
  • SSID Hidden
  • Firewall
  • DMZ
  • Parental Control

Environmental Conditions

• Operating Temperature: 0°C ~ 40°C
• Storage Temperature: -40°C ~ 70°C
• Operating Humidity: 5% to 95% RH (non-condensing)
• Storage Humidity: 5% to 95% RH (non-condensing)

Buttons

• WPS/Reset: 2-in-1 button
