ASUS ROG Strix Helios GX601 White Edition RGB

Case Specification

Model:

• ROG Strix Helios

Case Size:

• Mid Tower

Motherboard Support:

• EATX (12″x10.9″), ATX, Micro-ATX, Mini-ITX

Dimensions (WxHxD):

• 250 x 565 x 591 mm

I/O Panel:

• 1 x Headphone
• 1 x Microphone
• 4 x USB 3.1 Gen 1
• 1 x USB 3.1 Gen 2 Type-C
• LED Control Button
• Fan Control Button
• Reset Button

Storage Drive:

• 4 x 2.5″ Bays
• 2 x 2.5″/3.5″ Combo Bays

Water Cooling Support:

• Front: 120/140/240/280/360/420 mm
• Top: 120/140/240/280/360 mm
• Rear: 120/140 mm

Cooling Support:

• Front: 3 x 120 mm, 3 x 140 mm (Pre-installed)
• Top: 3 x 120 mm, 2 x 140 mm
• Rear: 1 x 120 mm, 1 x 140 mm (Pre-installed)

Maximum Cooler Dimensions:

• CPU Cooler Height: 190 mm
• GPU Length: 450 mm (requires a riser cable above 200 mm for vertical installation)
• PSU Length: 220 mm

Other Features:

• Tempered Glass (Front, Left, Right Sides)
• Removable Dust Filters (Front, Top, Bottom)
• Maximum Cable Management Space: 33 mm
• Weight: 18 Kg
• AURA Sync: ARGB

Expansion Slots:

• 8 horizontal, 2 additional vertical slots
